RSBTD Digital Double Shear Beam Load Cells

Counts for nominal load:
60000

Non-linearity:
± 0,02%F.S

Hysteresis error:
± 0,02%F.S

Repeatability:
± 0,01%F.S

Creep error after 30 min:
± 0,02%F.S

Combined error on nominal load:
± 0,01%

Temperature effect on full scale output:
± 0,02%F.S./10°C

Temperature effect on the zero
± 0,02%F.S./10°C

Compensated temperature range:
-10 °C / +40° C

Operating temperature range:
-30 °C / +70° C (not legal for trade use)

Power supply tension:
from 9 to 12 Vdc

Consumption:
15-20mA

Conversion:
24 bit

Connection:
RS485

Maximun Static Overload:
150% F.S.

Breaking Overload:
250% F.S.

Shielded cable:
Shielded PVC cable 4 poles, 6mm diameter.
