"WALL-E INOX" SERIES STAINLESS STEEL BENCH AND FLOOR SCALES

	"WALL-E INOX" SERIES STAINLESS STEEL BENCH AND FLOOR SCALES

Bench and floor scales with column, characterized by multifunction weight indicator, completely stainless steel structure. Easy to use and versatile, guaranteeing precision and reliability. Particularly suitable for industrial and commercial use. Available also in CE-M approved version according to OIML R-76 / EN 45501 standards.

TECHNICAL FEATURES

Weight indicator with waterproof IP65 STAINLESS STEEL case. Backlit 25mm LCD display with 6 high contrast digits and icons for indication of active functions. Waterproof 5-key functional keypad.
Functions with an aluminium load cell, protected in IP65 stainless steel cover, approved according to OIML R60 C3 standards (3000 divisions).
Stainless steel structure, with adjustable resting feet and level.
Stainless steel loading surface, size: see the table.
Support column, height:
- 350 mm in the "T" models;
- 500 mm in the "Q" models;
- 700 mm in the "X" models.
Digital calibration and set-up from keypad or from PC with DINITOOLS.
Power supply: 230 Vac power supplier.

SELECTABLE FUNCTIONS

X 10 high resolution visualisation
Net/Gross or lb/kg conversion
Weighs totalisation
Formulation
Counting
+/- Check
Percentage weighing
Alibi (with optional interface)
HOLD (freezing the weight on the display)

KEYBOARD AND PRINTING FUNCTIONS

KEYBOARD: Zeroing, Automatic tare, Presettable tare, printing and/or data transmission, selectable function command, on/off switching.
PRINTING: Configurable print layout with:
- 4 heading lines
- Gross-Tare-Net and ticket number
- Date and time (only with DFCLK)
- Print of barcode 39.

I/O SECTION

RS232/RS485 port for connection to PC, PLC or repeater.
RS232 port configurable for connection to printer.
IR input for managing the remote control.

OPTIONS ONLY AVAILABLE AT TIME OF ORDER

CE-M 3000e approved (OIML R-76 / EN 45501).
Real time clock.
Alibi Memory.
Infrared remote control.
USB interface.

PB platforms: capacities and dimensions

Code	Dimensions (LxPxH)	Max Capacity kg	Standard Division g	CE-M Division g (*)
WETI6	300x300x130	6	2	2
WETI15	300x300x130	15	5	5
WETI30	300x300x130	30	10	10
WEQI30	400x400x140	30	10	10
WEQI60	400x400x140	60	20	20
WEQI150	400x400x140	150	50	50
WEXI60	600x600x150	60	20	20
WEXI150	600x600x150	150	50	50
WEXI300	600x600x150	300	100	100

(*) These divisions are obtainable only with the relative options

Options only available at time of order

	Code	Description
	ECEM1A	CE-M 3000e approval for class III or IIII scales, with capacity from 1 to 30 kg.
	ECEM1B	CE-M 3000e approval for class III or IIII scales, with capacity from 31 to 1500 kg.
	SWM	WeiMonitor PC program for monitoring and recording in real time all the weighs executed on the connected scale.
	DFCLK	Real time clock for printing/displaying of the date and time.
	ALMEM	Alibi memory (fiscal memory, max 120.000 weighs) for approved transmission of the weight to PC/PLC. Real time clock integrated for print of the date/time.
	DFTL12	Infrared remote control, with 19 keys, for use up to 8 m of distance.
	USBMB	USB interface, as an alternative of the standard connector RJ, for quick connection of the indicator to PC.
	USBCABMB	USB cable for connection between indicator and PC (to be used with USBMB interface).
	RSCBRJ	RS232/C serial cable l= 1,5 m, for the connection of the weight indicator to PC, made up of 9-pole female connector on PC side and RJ connector on indicator side.
